Monsoon 3' X 4' Wet Downdraft Table

Overview

Designed for the safe removal of hazardous combustible dust, the Monsoon 3' X 4' Wet Downdraft Table is one of the most high-performing, cost-effective, wet dust collection solutions on the market. Equipped with a powerful integrated blower, its high capture velocity collects more contaminants from a wider surface area, than other competing models.

The Monsoon 3’ x 4’ safely captures combustibles by pulling contaminated air through the ventilated work surface and moving them into a torrent of water. The dust particles then bond with suspended water droplets before draining down to the bottom of the collector for safe removal.

The Monsoon 3’ x 4’ Wet Downdraft Table’s plug and play design allows for quick and easy installation. The cabinet’s stainless steel construction guards against corrosion and the collector’s internal components can be removed for easy cleaning. A protective rubber grid mat comes included to protect delicate parts from damage.

Designed for the safe collection of combustible metal dusts, ideal applications include: aluminum, magnesium, titanium, grinding & deburring, sanding & finishing, 3D printing, powder mixing and plastic dust.

Benefits

• Capture-at-source for cleaner air
• Industrial swivel castors included for portability
• Compliant with NFPA guidelines for combustible dust
• Integrated overhang for seated operations
• Self-contained, compact design

Features

• Flexible 49” x 36” Worksurface
• High Capture Face Velocity (250 FPM)
• 5 HP TEFC Motor producing 3000 CFM of Airflow
• Stainless Steel Anti-corrosion Construction
• Auto-Level Water Control System
• Standard Rubber Cushion Grid Mat
• Standard Exhaust Silencer

Options

• Auto Wash-down System
• WV-55 Sludge-Vac
• Side and Back Walls
• HEPA Afterfilter Kit (99.99% @ 0.3 micron)
• Dust-Tight / Vapor-Tight Light Kit
• Custom configurations available on request
