DD 3' X 4' Downdraft Booth

Overview

The trusted choice of North America’s largest manufacturers, Diversitech’s 3' X 4' Downdraft Booths are built to withstand the most demanding applications. With a ventilated work surface 3′ deep by 4′ wide, you can configure the 3' X 4' Downdraft Booth to suit dozens of industrial applications. Fumes, smoke and dust are captured right at source so indoor air quality remains uncompromised.

As a standard feature, the table comes fitted with multi-stage spark arrestance baffle for fire prevention and dual 10” exhaust silencers for noise reduction. An automatic reverse-pulse filter cleaning system reduces overall maintenance requirements.

Equipped with a high enclosure that includes a ceiling and side and back panels, the booth prevents contaminants from escaping the backdraft hood and improves the performance of your table. Whether you weld, grind, debur, cut, sand, finish, solder, paint or mix, the DD 3' X 4' Downdraft Booth provides the perfect, flexible, all-in-one solution.

Benefits

• Built-to-order for your specific needs
• Capture-at-source for cleaner air
• Compliant with OSHA and NFPA guidelines
• Automatic self-cleaning for easy maintenance

Features

• Flexible 48” x 42” Enclosed Worksurface
• High Capture Face Velocity (450 FPM)
• On-demand, Reverse Pulse Cleaning System
• Multi-stage Spark Arrestance Baffling
• Dust Drawer for Easy Servicing
• Dual 10" Exhaust Silencers

Options

• Odor Absorption Kits
• Tabletop Capture Arm
• Minihelic Gauge
• Dual HEPA Afterfilter with Frame
• Blue Cushion Grid Matting
• 3" Swivel-casters, set of four (4)
